310.508Y

TPI COMPACT MEASURING TAPE “BRISTOL”
* One time measuring up to 5 meter
* Fits easy in most hands and pockets
* Optimum measuring comfort & long blade stand
* Easy to attach to most (working) pants or belts
* Suitable for professional and DIY-workers
* Increases the productivity on the job site
* Perfect to carry & clip on TP tool holder 360.074 – Toolvizion

TPI; 3MX16MM COMPACT MEASURING TAPE “BRISTOL” SERIES
REFERENCE  SIZE BLADE  DIAMETER  WIDTH  WEIGHT      EAN-CODE           HS-CODE
310.508Y      3mx16mm    57mm         25mm   80 gr.          8714612044803  9017801000
310.512Y      5mx19mm    70mm         30mm   170 gr.        8714612044841  9017801000

FEATURES & SPECIFICATIONS :
CE/MID approved, 2014/32/EU, Art. 17, Accuracy Class II
Blade size : length: 3 meter / Width: 16mm
Blade: Quality white colored steel
Single sided black colored graduation
Metal end-hook with 2 metal rivets
High impact yellow colored ABS case
ABS ribbed thumb-lock
Added compact ABS side-lock
Metal belt clip & polyester wrist strap
ToolVizion EU Type examination certificate available upon request
Manufactured in: PRC
Individual packing: in neutral carboard box

Packed :
310.508Y : Inner Carton: 10 pieces / Master Carton: 200 pieces

Master carton; 40 pieces / Gr. Weight: 20 Kg.
310.512Y : Inner Carton: 10 pieces / Master Carton: 100 pieces

MOQ AND DELIVERY TIME FOR PRIVATE LABEL  : ON REQUEST
